Packaging machine from ZAHORANSKY benefits from bus-compatible SIKO position indicator for size changeover

Z.PACK 4 with semi-automatic insertion handling – all stations are equipped with SIKO position indicators for the shortest possible refitting times.

The packaging machines that are equipped with the ERCO system are in the Z.PACK series. They are suitable for blister packaging of all types, for anything from stationery, tools, electronic items and automobile accessories to cosmetics and medical products. Each Z.PACK machine has various stations of different designs and lengths through which the blister packs pass during the packaging process.

As Jörg Philip Zimmermann, Head of Product Sales Packaging, explains regarding ZAHORANSKY’s requirements for the packaging machines: “Our aim was to design the Z.PACK in such a way that the process would be reliable enough to eliminate operating errors and therefore waste and damage to the machines. We also wanted to reduce the refitting times significantly and thus save money for our customers.” The packaging division was able to see how this could be possible through comparison with their colleagues in the brush machine business unit, where monitored size changeover in a brush machine with an electronic position indicator from SIKO has already been implemented successfully. The aim was to integrate this system into the Z.PACK packaging machines too.

Bus-compatible position indicator with status LEDs
Compared to the brush machine, the distinctive feature in the Z.PACK machine is a result of the linear movement for which a monitored size changeover was to be implemented. The individual stations on the packaging line are moved in a straight line on two guide rails and must be repositioned precisely for each changeover. The ERCO concept already plays a part in this: thanks to the quick changeover system, the individual stations can be moved with minimum effort using your little finger.

In order to ensure the process reliability still further, ZAHORANSKY has opted for AP10S electronic position indicators from SIKO with a linear magnetic sensor connected to them. This facilitates precise linear measurement of the manual slide adjustment on the guide rails. The bus interface is what sets the electronic AP10S indicator apart from mechanical variants. Thanks to bus integration in the position display, the process reliability required is achieved centrally via the machine controller (PLC). The PLC sends target values to the position indicator and reads the actual values measured. The target values are set up in a recipe management system within the machine controller, i.e. there is a recipe with all of the relevant target values, such as the station positions, for each of the products to be made. By means of the position status transmitted, the machine controller does not enable the entire system until feedback is received to confirm that all the positions set manually are correct, effectively preventing waste and damaged format parts as a result of adjustment axes being set up incorrectly.

The distinctive feature is that the position status is displayed visually by means of LEDs: green for “Position correct” and red for “Position not correct”. This provides the operator with immediate and clear information about whether the station in question has been positioned correctly or readjustment is necessary. The external magnetic sensor for determining the correct position measures extremely precisely with an absolute accuracy of up to +/- 35 µm. Only when all of the LEDs turn green following adjustment can the packaging machine be put back into operation.

The green LEDs of the SIKO AP10S position indicator clearly indicate that the stations on the Z.PACK are set up correctly and the packaging process can continue.

Z.PACK: Standard modules and additional functions
The Z.PACK standard machine with a chain length of four meters includes the following stations, each of which can be equipped with the AP10S position indicator: the material infeed, into which the blister film is fed via a chain system, is followed by the heating and deep drawing systems, into which the SIKO position indicators can be integrated. Here the film is preheated and deep-drawn with a blister mold that matches the mold stamp – as a positive or negative mold. The product is then inserted, either by hand or fully automatically by means of a pick-and-place unit. Then the cover material, such as cardboard, Tyvek, aluminum, PET or PVC film, is fed in and the whole thing is sealed, either by heat sealing or, optionally, ultrasound sealing.

Finally, partial or complete cutting is carried out. Depending on the needs of the customer, additional stations can also be integrated (possible on Z.PACK series with a chain length between five and eleven meters), which can also be equipped with position indicators for size changeover: insertion of leaflets, laser or inkjet printing, blind imprinting on the packaging edge, perforation of cardboard and film, folding of the filled blisters, camera-aided monitoring and scanning of barcodes are all possible. All stations must be adjusted to the new film width on every product change – and this must be done very precisely. Cutting contours for the blister packs must be exact for a perfect product, as must the seal surfaces. The SIKO position indicators play a part in achieving this precision.


Refitting times halved thanks to monitored size changeover
Inclusion of the AP10S is optional for Zahoransky customers, but it is always recommended because of the positive impression it has made. Especially for customers who have to carry our size changeovers on their systems frequently, such as contract packing companies, setting up monitored size changeover pays off. The cost-efficiency argument is particularly important for ZAHORANSKY, as Jörg Philip Zimmermann explains: “The benefits are immediately perceptible. Setup work is cut to a minimum; conversion to a new product takes place perceptibly more quickly, precisely, safely and ergonomically for the operator. In fact, we are able to halve refitting times with the SIKO position indicators.” This has a positive impact on the availability of the system, which is ready for production much more quickly, and on output, as waste is avoided completely.

Moritz Müller, PositionLine Product Manager at SIKO, is delighted by the extension of cooperation between the companies: “Our mechanical position indicators have long been part of the basic equipment in numerous ZAHORANSKY machines with size changeovers. In recent years, the company has taken a number of steps in the direction of monitored size changeover – the keyword being ERCO – and in doing so has put its trust in SIKO’s technical competence. In view of the high level of process reliability and the significant reduction in setup times, the demand for intelligent, monitored size changeover is increasing among Zahoransky customers. This has now led to an extension of our cooperation in the packaging division.”

Author: Michaela Wassenberg, Freelance journalist

Characters: 6.732

Characters with spaces: 7.654

The stations mounted on guide rails can be adjusted easily and quickly on the Z.PACK – thanks to SIKO position indicators
